Attributes of Emax BL2832/05 kv805 RC Brush-less Out-runner Motor Pull Upto 3.1kg

Specifications:

• Model: BL2832
• Cell count: 4S
• RPM/V: 805
• Prop (APC): 13*6.5
• RPM: 9100
• MAX current(<60s): 69A
• Thrust: 3150g
• No. of cells: 4*Li-Poly
• Stator dimensions: 30*32mm
• Shaft diameter: 5mm
• Weight: 210g/7.4oz.
• Recommended model weight: 2000g-4000g
• Recommended prop without gearbox: 13*8 14*7
• Recommended model: Airplane

Package:

• 1*Motor
• 1*Motor Block
• 3*Banana Plug
• 1*Pulp clip
• 8*Screws weight=264g

Features of Emax Out-runner Motor:

Emax Out-runner Motor Based on Simon K firmware, further optimized to perfect drive performance.
Low-voltage protection, over-heat protection, and self-check functions.
Separate power supply for MCU and BEC, enhancing the ESC’s ability to eliminate magnetic interference.
The parameters of the ESC can be set via a program card or transmitter.
The throttle range can be set to be compatible with different receivers.
Equipped with built-in BEC.
Max speed: 210,000 rpm for 2-pole, 70,000 rpm for 6-pole, 35,000 rpm for 12-pole.
