QX Motor 70EDF 6 Blades Electric Ducted Fan (QF2827-3800KV) for RC Jets | High-Speed EDF with Powerful
₹5,200.00
Only 1 left in stock (can be backordered)
- Satisfaction Guaranteed
- safe Transportation
- Secure Payments
Description
Attributes of QX Motor 70EDF 6 Blades Electric Ducted Fan (QF2827-3800KV)
Take your RC jets to the next level with the QX Motor 70EDF 6 Blades Electric Ducted Fan (QF2827-3800KV), designed for high-speed performance. Featuring a powerful QF2827-3800KV brushless motor, this EDF unit is optimized for fast and agile flights. The 6-blade configuration ensures efficient airflow and balanced thrust, making it perfect for small to medium-sized EDF jet models. Whether you’re flying on 3S or 4S LiPo batteries, the 70EDF offers excellent speed, reliability, and smooth flight performance. Ideal for hobbyists looking for enhanced RC jet performance, available now at FlyingMachines.in!
Technical Data:
- Motor Model: QX Motor QF2827-3800KV
- Fan Diameter: 70mm
- Blade Count: 6
- Motor Type: Brushless Outrunner
- KV Rating: 3800KV
- Input Voltage: 3S to 4S LiPo (11.1V to 14.8V)
- Power Output: 600W – 900W (Approximate)
- Max Thrust: ~1.2kg on 3S, ~1.5kg on 4S
- Mounting Shaft Diameter: 3.17mm
- Weight: 110g (including motor and fan)
- Applications: Suitable for 70mm EDF jet models
- Material: High-quality nylon plastic (fan), aluminum alloy (motor casing)
- Recommended ESC: 40A to 60A (depending on battery setup)
- Connector Type: 3.5mm bullet connectors
- RPM Range: 25,000 – 35,000 RPM (depending on input voltage)
Package Includes:
- 1 x QX Motor 70mm EDF Unit (6 Blades)
- 1 x QF2827-3800KV Brushless Outrunner Motor (Pre-installed)
- 3 x 3.5mm Bullet Connectors (Pre-installed on motor wires)
- 1 x Mounting Adapter
- 4 x Screws for secure mounting
Click Here For More Products.
Additional information
| Weight | 75 g |
|---|
